Description

US-751 is a user-friendly ultrasound therapy unit with Multi-frequency.
Ultrasound frequency: 1 & 3 MHz
Ultrasound mode: continuous and pulsed
Intenstiy(max): 2W/cm² for continuous mode and 3 W/cm² for for pulsed mode.
Duty Cycle: 5,10,20,30,40,50, and 100 %
Time: 1 – 30 min (counts only actual therapy time)

Large 7 inch TFT color touch screen
Both small probe & large probe can be connected
(also containing probe holder)
Display probe contact status on both the probe and main unit
Automatic cutoff the ultrasound waves in the event the ultrasound head separates from the patient’s skin contact-reduces the ultrasound head damage
Low BNR, Beam Non-uniformity Ratio: 2.4-3
42 protocols by the whole body parts included.
